Revit Structure Reinforcement and Scheduling

Revit users with a requirement to produce RC detailing can benefit from the skills and knowledge provided in this course. You will gain an understanding of how to confidently place, schedule and design reinforcement for all concrete elements. This 1-day Revit Structure Reinforcement and Scheduling course is your chance to learn the best techniques for quick and accurate detailing and scheduling.

Course content for Revit Structure Reinforcement and Scheduling

  • Create a concrete element – design a custom reinforcement element to add rebar into
  • Add single/multi-bar reinforcement to concrete elements
  • Add area, path and fabric reinforcement to concrete slabs
  • Set rebar cover depth – learn easy-to-change rebar adjustment cover settings
  • Use these tools to amend and auto-adjust existing rebar
  • Adjust reinforcement settings – adjust all aspects of rebar from rounding to presentation
  • Sketch rebar shapes – create custom bar shapes to suit any shape or sized reinforced element
  • Add area, path & fabric reinforcement – easily apply and adjust multi-bar rebar placement
  • Save countless hours of work with automated schedules which count all rebar sizes, numbers, etc.
  • Easily adjust and edit schedules with fully customisable fields which link to the modelled rebar
  • Put all your new skills into practice in an extended afternoon lab session

Benefits of Revit Training

Create complex designs simply

Learn tools for automating tedious work

Save countless hours of calculating and amending schedules

Put your new skills into practice by the end of the course

Expected outcome

As a result of attending this training, you will be able to use add single/multi-bar reinforcement to concrete elements, add area, path and fabric reinforcement to concrete slabs, change and modify all reinforcement settings including cover and rounding, create and modify rebar schedules

After completing the course, you can log into your personal student account and download your official Autodesk Certificate of Completion.

Expected outcome
